Victron BlueSolar PWM-Light Charge Controller 48V-10A
SKU: SCC040010020 Learn More»
FREE SHIPPING
This item is sent via Express Courier. All freight is fully insured.
Product Description
Victron BlueSolar PWM-Light Charge Controller 48V-10A, 5 Years Warranty.
BlueSolar PWM-Light
- Load output with low battery voltage disconnect function.
- Lighting control function, one timer only.
- Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
- Three stage battery charging (bulk, absorption, float), not programmable.
- Load output protected against over load and short circuit.
- Protected against reverse polarity connection of the solar array and/or battery.
- Day/night timing options: see manual for details
Features:
- Load output with low battery voltage disconnect function.
- Lighting control function, one timer only.
- Seven segment display for quick and easy setting of the load output functionality, including timer setting.
- Three stage battery charging (bulk, absorption, float), not programmable.
- Load output protected against over load and short circuit.
- Protected against reverse polarity connection of the solar array and/or battery
Specifications:
- Battery Voltage - 48V
- Rated charge current - 10A
- Automatic load disconnect - Yes
- Maximum solar voltage - 100 V
- Self-consumption - < 10 mA
- Load output - Manual control + low voltage disconnect
- Protection - Battery reverse polarity (fuse) Output short circuit Over temperature
- Overload protection - Shut down after 60 s in case of 130% load |Shut down after 5 s in case of |160% load Short circuit: immediate shutdown.
- Grounding -Common positive
- Operating temp. range -20 to +50°C (full load)
- Humidity (non-condensing) - Max 95%
- Charge voltage 'absorption' - 56.8V
- Charge voltage 'float' - 55.2V
- Low voltage load disconnect - 44.8V
- Low voltage load reconnect - 50.4V (manual) 52.4V (automatic)
- Protection class - IP20
- Terminal size - 6 mm² / AWG10
- Weight - 0.17kg
- Dimensions (h x w x d) - 95 x 140 x 33.5 mm
Specifications
SKU SCC040010020
Brand Victron
GTIN 8719076025573
Warranty Period: 5 Years
Product Category Solar Charge Controllers
Charge Current (A) 10
Voltage 48V
Dimensions 33.5 x 140 x 95 (D x W x H)
Amps 10
Humidity Max 95%
Protection Battery reverse polarity (fuse), Output short circuit, and Over temperature
Operating temperature range -20 to +50°C (full load)
Charge voltage 'absorption' 56.8V
Net Weight (kg) 0.17
