Victron BlueSolar PWM-Pro Charge Controller 12/24V-5A

SKU: SCC010005010 Learn More»

Quantity

Postcode

Suburb

$99

$29

$29

$59

Click '+' to show more accessories

Call 1300 400 122

Add To Wishlist

Customer Reviews

Product Description

Victron BlueSolar PWM-Pro Charge Controller 12/24V-5A, 5 Years Warranty.

The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable.

Lighting control function, fully programmable.
Three stage battery charging (bulk, absorption, float), fully programmable.
Integrated battery monitor function (Remote Panel needed to display state of charge).
Load output with low voltage disconnect and manual control (default setting).
Optional external temperature sensor.
Load output protected against over load and short circuit.
Protected against reverse polarity connection of the solar panels and/or battery.
Day/night timing options: see manual Remote Panel for details.

Programmable
The BlueSolar PWM-Pro series is ready for use with its default settings. It also is fully programmable:

With help of a computer and software (available free of charge from our website)
With the dedicated BlueSolar Pro Remote Panel (see features below).

Features:

Lighting control function, fully programmable.
Three stage battery charging (bulk, absorption, float), fully programmable.
Integrated battery monitor function (Remote Panel needed to display state of charge).
Load output with low voltage disconnect and manual control (default setting).
Optional external temperature sensor.
Load output protected against over load and short circuit.
Protected against reverse polarity connection of the solar array and/or battery

Specifications:

Battery Voltage - 12/24V with automatic system voltage detection
Rated charge current - 5A
Automatic load disconnect - Yes
Maximum solar voltage - 28V / 55V (1)
Self-consumption - < 10 mA
Load output - Manual control + low voltage disconnect
Protection - Battery reverse polarity (fuse) Output short circuit Over temperature.
Grounding -Common positive
Operating temp. range -20 to +50°C (full load)
Humidity (non-condensing) - Max 98%
Charge voltage 'absorption' - 14.4V / 28.8V
Charge voltage 'float' - 13.8V / 27.6V
Equalization charge - 14.6V / 29.2V
Low voltage load disconnect - 11.1V / 22.2V
Low voltage load reconnect - 12,6V / 25,2V
Protection class - IP30
Terminal size - 4 mm² / AWG10
Weight - 0.13kg
Dimensions (h x w x d) - 138x70x37 mm
