Victron BlueSolar PWM-Light Charge Controller 12/24V-20A

Product Description

Victron BlueSolar PWM-Light Charge Controller 12/24V-20A, 5 Years Warranty.

BlueSolar PWM-Light

• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery.
• Day/night timing options: see manual for details

Features:

• Load output with low battery voltage disconnect function.
• Lighting control function, one timer only.
• Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.
• Three stage battery charging (bulk, absorption, float), not programmable.
• Load output protected against over load and short circuit.
• Protected against reverse polarity connection of the solar array and/or battery

Specifications:

• Battery Voltage - 12/24 V with automatic system voltage detection
• Rated charge current - 20A
• Automatic load disconnect - Yes
• Maximum solar voltage - 28V / 55V (1)
• Self-consumption - < 10 mA
• Load output - Manual control - low voltage disconnect
• Protection - Battery reverse polarity (fuse) Output short circuit Over temperature
• Overload protection  - Shut down after 60 s in case of 130% load |Shut down after 5 s in case of |160% load Short circuit: immediate shutdown.
• Grounding - Common positive Operating temp. range -20 to +50°C (full load)
• Humidity (non-condensing) - Max 95%
• Charge voltage 'absorption' - 14.2V / 28,4V
• Charge voltage 'float' - 13.8V / 27,6V
• Low voltage load disconnect - 11,2V / 22,4V
• Low voltage load reconnect - 12,6V / 25,2V (manual)  |13,1V / 26,2V (automatic)
• Protection class - IP20
• Terminal size - 5 mm² / AWG10
• Weight - 0.15kg
• Dimensions (h x w x d) 70 x 133 x 33.5
