Baintech 12V 150Ah Deep Cycle Slimline Lithium Battery with 200Amp BMS

Take an EXTRA $40 OFF! Add to cart to get an instant discount.
Sale Ends in

FREE SHIPPING

Learn More»

Customer Reviews

Go to: Product Details

Go to: Specifications

Product Description

Baintech 12V 150Ah Deep Cycle Slimline Lithium Battery with 200Amp BMS, 5 Year Warranty. The 12V 150Ah Lithium Battery with 200ah BMS & digital display is perfect for powering your 12V set-up including up to 2000W inverter. This slimline lithium battery is strong and safe due to its aluminium casing and built-in BMS that protects you from temperature, over-voltage, and short circuit. Our unique BMS will further increase safety and durability. Can be connected in parallel for increase capacity, and connected in series for increase voltage Max 48V.

Specifications:

Max Charge Current – 150A, 200 Continuous outflow
Peak current – 300A-350A (10s)
BMS Low Voltage Cut-off – 8.8V (2.2+0.05v) pc)
BMS Reconnect voltage – 10.8V (2.7+0.05v) pc)
Weight – 17kg
Case dimension (L*W*H) – 520 x 270 x 90mm
Cell type / Chemistry – LiFePO4 chemistry
BMS: low voltage, high voltage, over temperature
Over current, short-circuit protection, Balancing etc.
Discharge Temperature -20～+65℃
Charge Temperature 0～+45℃
Storage Temperature Range 0～+45℃
Battery High Temperature Protection 60℃
Guaranteed 5 year warranty

Go to: Product Details

Go to: Videos

Specifications

SKU BTLP12V150-200SL

Brand Baintech

Warranty Period: 5 Years

Product Category Batteries

Battery Voltage 12V

Amp Hours (ah) 150

Product Type Lithium(Slimline) Battery

Continuous Current 200A

Dimensions 520 x 270 x 90mm

Peak Current (10s) 300A-350A

Weight (kg) 17

Go to: Specifications

Go to: Reviews

Videos

Baintech's Lithium Dual Camping Battery Setup

Why Weight Should Be Your Priority When Choosing A 4WD Battery

Do you need a Dedicated Lithium Battery Charger?

AGM vs Lithium Batteries For Your 4WD

Why Lithium Batteries are Cheaper in the Long Run

Baintech's Guide To Choosing A Marine Battery: Lithium For Your Boat

AGM vs Lithium: Why Lithium Batteries Are The Better Option For Your 4WD

Introducing The New Australian Made Baintech Lithium Battery Range

How to charge & run appliances from the Baintech in-built DC-DC Lithium Battery Range

New 150Ah Slimline Lithium Battery with Digital Display

Go to: Videos

Go to: Q & A

Customer Reviews

Write a product review

Go to: Reviews

Go to: Warranty

Product Q&A

Ask Us a Question

Which Battery Charger is suitable for my 95Ah Baintech Slimline Lithium Battery?

Baintech recommends the Victron 7A IP65 Smart Charger – it has a dedicated lithium charging profile suited to the Baintech Lithium Batteries. You will need to adapt the charger leads to a Grey Anderson Plug.
hii have a RedArc- bcdc1240d charger as i have a solar panal on the roof of my car. Will this do the job of charging the slimline lithium battery? thanksMark

HI Mark,

Whilst the BCDC1240D is primarily designed for batteries of 200Ah or larger, there should be no issue using it to charge the slimline battery. It can handle a maximum charge current of 100A
It says to use a 100a fuse , is that leading from the car / starter battery into the lithium battery? or from the lithiumbattery out to accessories?

Hi There,

A 100A fuse is required for both Anderson plugs on the side of the battery.

These Anderson plugs can both be used for charging or for loads, thus requiring a fuse on each one.
why does your information state 50a BMS but the baintech site states 100a BMS?

Hi There,

It looks like the spec has been updated since we uploaded this product. These will come with a 100A BMS per the specs from Baintech.
Hi,Some of the reports/websites state that this battery has an in-built DC-DC charger, however the specs and Baintech site don't specify that. Are you able to confirm whether or not it has any type of charging interface within and whether or not it can b

Hi There,

This battery does not have an included DC DC charger.
