Exotronic Compatible Solar Connector Pair

Product Description

Exotronic Compatible Solar Connector Pair, 1 Year Warranty.

Exotronic Compatible Connector Pair: The Ideal Choice for Solar Panel Connectivity
Introducing the Exotronic Compatible Solar Connector Pair – your reliable solution for secure and efficient solar panel connections. These connectors are expertly designed to meet the demands of any solar power system, from small RV setups to large-scale off-grid installations. The connectors are compatible with MC4 Connectors.

Weather-Resistant Design for Uninterrupted Power Supply
Featuring a robust IP67 waterproof and dustproof rating, these connectors ensure a consistent power flow even in harsh weather conditions. The high withstand voltage of DC 1000V makes them suitable for a variety of solar applications. Constructed with top-quality tinned copper, these connectors provide excellent conductivity and corrosion resistance.

Durable Materials for Long-Lasting Solar Connections
The use of PC/PPO as insulation material enhances durability, while the copper alloy with tin plating ensures a stable and long-lasting connection. The connectors operate efficiently within a wide temperature range of –40°C to +90°C, making them versatile for different climates.

Advanced Safety Features for Reliable Solar Installations
Safety and reliability are paramount with these connectors. They come with a snap-in locking system for secure attachment, have a low contact resistance of 0.5mΩ, and meet the UL94-V0 flame class standard. Rated for currents up to 30A, these connectors are compatible with a range of wire sizes, making them a flexible choice for your solar energy needs.

Choose the Exotronic Compatible Solar Connector Pair for a seamless solar experience, ensuring your panels are connected safely, efficiently, and reliably.

Specifications:

• Waterproof and Dustproof (Mated): IP67
• Waterproof and Dustproof (Unmated): IP2X
• Rated Voltage: 1000V DC (IEC)
• Contact Material:  Tinned Copper
• Insulation Material: PC/PPO
• Contact Material: Copper Alloy, Tin Plated
• Temperature Range: –40°C to +90°C (IEC)
• Upper Temperature Limit: +105°C (IEC)
• Degree of Protection (Mated): IP67
• Degree of Protection (Unmated): IP2X
• Flame Class: UL94-V0
• Locking System: Snap-in
• Contact Resistance of Plug Connectors:  0.5mΩ
• Safety Class:  II
• Test Voltage: 6kV (50Hz, 1min)
• Salt Mist Spray Test, Severity Degree: 5 (according to IEC 60068-2-52)
• Rated Current: 17A (1.5mm²), 22A (2.5mm²; 14AWG), 30A (4mm², 6mm²; 12AWG, 10AWG)
• Connector System: Ø 4 mm
