Victron SmartSolar MPPT 250/85-MC4 VE.Can Charge Controller

$913

Save $141 (13%) off RRP of $1,054

Take an EXTRA $30 OFF! Add to cart to get an instant discount.
Sale Ends in

FREE SHIPPING

Accessories

$67

$74

$24

$35

$67

$88

Click '+' to show more accessories
Learn More»
Dispatch 5-7 Days Express Shipping Price Match Guarantee Customer Reviews

Product Description

Victron SmartSolar MPPT 250 VOC / 85A MC4 VE.Can Charge Controller, 5 Year Warranty.

Solar charge controller:

The MPPT VE.Can SmartSolar charger uses the latest and fastest technology to convert energy from a solar array into energy that optimally charges a battery banks.

The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damage.

MPPT: Ultra Fast Maximum Power Point Tracking:

The MPPT VE.Can SmartSolar charger connects to a PV array of 150 or 250 Volt Voc and will automatically detect and charge your 12, 24, or 48V battery bank with current ranging from 70 to 100A depending on the model.

The charge settings are fully programmable and can even be set up for different battery chemistries, like lead-acid, lithium and others.

Control Your Charger Remotely:

The MPPT VE.Can SmartSolar charger can be remotely controlled and configured over Bluetooth via the VictronConnect App. This allows device set-up, management, and at-a-glance information, such as battery voltage and current, PV voltage and current, and historical data.

Daisy Chain Additional Units:

The VE.Can SmartSolar charger is equipped with CAN bus ports. This allows for communication with additional VE.Can SmartSolar chargers. The additional units are simply “daisy chained” to each other with a single RJ45 cable between the individual units.

When connected to each other, all individual VE.Can SmartSolar chargers, will synchronise their charge stages. They can also send their data, via a single cable, to a GX monitoring device.

Remote Monitoring and Control:

If the GX device is connected to the internet, the Victron Remote Management Portal (VRM) provides access to the full power of your solar charger(s).

SmartSolar Control Display:

The VE.Can SmartSolar charger is also equipped with a VE.Direct port like our other MPPT solar chargers. This port can be for single unit monitoring or for streetlight control. The remote on/off connector can be externally controlled by a third-party device like a lithium battery. An optional plug-in LCD display/control provides live-data, set-up and management, straight from the face of the device.



Victron PI12/2000 Product Card

Product Manual

Product Drawing

Specifications

SKU SCC125085511

Brand Victron

GTIN 8719076050902

Warranty Period: 5 Years

Product Category Solar Charge Controllers

Charge Current (A) 85

Net Weight (kg) 4.5

Efficiency 99% (Max)

Humidity 95%, non-condensing

Voltage 12/24/48V Auto Select (36V: manual)

Nominal PV Power 12V - 1200W | 24V - 2400W

Operating temperature range -30 to +60°C (full rated output up to 40°C)

Amps 85

Charge voltage 'absorption' Default Setting: 14.4 / 28.8 / 43.2 / 57.6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth)

Protection PV reverse polarity / Output short circuit / Over temperature

Dimensions 103 x 295x 216 (D x W x H)
